Honeywell Minitrend QX User Manual

43-TV-25-30 Iss.6 GLO Aug 07 UK 53
Table 4.1 : Card Positions and Channel Numbers
Minitrend QX
Slot position Card type
Channel
numbers
Slot A 8 Analogue In
Pulse Inputs
1 to 8
1 to 4
Slot B 8 Analogue In
Pulse Inputs
4 Analogue Out
9 to 16
9 to 12
9 to 12
Slot G 4 Relay Output
8 Relay/2 Digital In
8 Digital Input/Output
16 Digital Input/Output
1 to 4
1 to 8
1 to 8
1 to 16
Multitrend SX
Slot position Card type
Channel
numbers
Slot A 8 Analogue In
Pulse Input
1 to 8
1 to 4
Slot B 8 Analogue In
Pulse Input
9 to 16
9 to 12
Slot C 8 Analogue In
Pulse Input
17 to 24
17 to 20
Slot D 8 Analogue In
Pulse Input
25 to 32
25 to 28
Slot E 8 Analogue In
Pulse Input
4 Analogue Out
33 to 40
33 to 36
33 to 36
Slot F 8 Analogue In
Pulse Input
4 Analogue Out
41 to 48
41 to 44
41 to 44
Slot G 4 Relay Output
8 Relay/2 Digital In
8 Digital Input/Output
16 Digital Input/Output
1 to 4
1 to 8
1 to 8
1 to 16
Slot H 4 Relay Output
8 Relay/2 Digital In
8 Digital Input/Output
16 Digital Input/Output
17 to 20
17 to 24
17 to 24
17 to 32
Slot I 4 Relay Output
8 Relay/2 Digital In
8 Digital Input/Output
16 Digital Input/Output
33 to 36
33 to 40
33 to 40
33 to 48
