Honeywell Minitrend QX

12 43-TV-25-30 Iss.6 GLO Aug 07 UK
Mounting Clamp Diagram
2 mounting clamp 
positions required on
two opposite sides of
the recorder. Nema 4X
requires all 4 clamps to
be fitted.
Mounting clamp slots
Figure 2.1 Minitrend QX and eZtrend QXe Mounting clamp
Figure 2.2 Multitrend SX Mounting clamp
4 mounting clamp
positions (2 shown). 
2 clamps are re-
quired on opposite
sides of the recorder
