43-TV-25-30 Iss.6 GLO Aug 07 UK 111
Batch process screen
To show a batch related process screen the screen must be configured to display the group
being used for that batch. Under the message count icon it will show the current status for
the batch related to that group. The message list status bar will also show the Batch name,
state and group name in rotation with the date/time display. An extra button is now available
within the message button on the status bar to show the current status of the batches for all
groups.
Note: on non batch screens the message list icon no longer shows the batch state as there
are potentially 6 batches running in different states
Printer Menu
(Configure > Setup > Edit Setup> General > Printer)
The Printer function is a firmware option that is selectable from the Factory menu > “Cred-
its” on page 102. The screens that currently can be printed are all Status screens, Mes-
sage lists, Process screens and Replay screens.
The printer network information should be entered prior to printing, see “Network Admin”
on page 75. If the information is not entered in the Network Admin menu a dialog box will
appear prompting you to enter Username, Password and Domain. Entering this information
into the dialog will not populate the Network Admin menu. It is recommended that you fill in
this information into the Network Admin menu as it will not be affected by Firmware up-
grades in the recorder.
