Table 10.2 :
Multitrend SX - Spares
1 51453012-501 SX Processor Board Assy
2 51453006-501
51453006-502
51453006-503
SX Analogue Input 4CH Assy
SX Analogue Input 6CH Assy
SX Analogue Input 8CH Assy
2 51453027-501
51453027-502
SX Analogue Output 2CH Assy
SX Analogue Output 4CH Assy
2 50001017-502 SX Pulse Input 4CH Assy
3 51453024-501 SX Mother Board Assy
4 51453018-501
51453018-502
SX Digital I/O 8CH Assy
SX Digital I/O 16CH Assy
4 51453021-501
51453021-502
SX Relay Alarm 4CH Assy
SX Relay Alarm 8CH Assy
5 50001182-501
50001182-502
SX Power Supply AC Mains
SX Power Supply 20-55VDC/20-
30VAC
6 51453030-501 SX Transmitter Power Supply board
11
50013946-501
50013946-502
SX Bezel/Touch Screen Std and
Nema 3/IP54 Door
SX Bezel/Touch Screen and Nema
4X/IP66 Door Assy
Includes Bezel, Touch
Screen and Door
14 50009119-501 SX Std Nema 3/IP54 Door
15 50003590-501 SX Nema 4X/IP66 Door
23 50001782-501 QX / SX Speaker Assy
27 50006787-501 QX / SX Battery (kit of 5) Not shown
28 50001011-503
50001011-504
50001011-505
50001011-506
50001011-507
50001011-508
Compact Flash card 128Mb
Compact Flash card 256Mb
Compact Flash card 512Mb
Compact Flash card 1Gb
Compact Flash card 2Gb
Compact Flash card 4Gb
Not shown
30 50006809-502
50006809-501
SX Display/Bezel/Touch Screen Assy
NEMA 4X/IP66
SX Display/Bezel/Touch Screen Assy
NEMA 3/IP54
Includes Bezel, Touch
Screen and Display
