250 43-TV-25-30 Iss.6 GLO Aug 07 UK
Table 10.3 :
eZtrend QXe - Spares
1 50012923-501
50012923-502
QXe Processor Board/ 3 CH. Analogue
Input with Ethernet Assy
QXe Processor Board/ 6 CH. Analogue
Input with Ethernet Assy
Standard
2 51453006-502 QXe Analogue Input 6CH Assy Requires Expansion
card item 3
3 50012927-501 QXe Expansion Board Assy Required for items 2, 4
and 6
4 51453018-501 QXe Digital I/O 8CH Assy
4 51453021-501
51453021-502
QXe Relay Alarm 4CH Assy
QXe Relay Alarm 8CH Assy
5 50015140-501
50015140-502
QXe Power Supply AC Mains
QXe Power Supply 20V/30VDC/20-
25VAC
6 50012930-501 QXe Communications card plus 24V
DC Transmitter Power Supply (RS485
Modbus RTU and USB port)
7 50016251-501 QXe Bezel/Touch Screen and Nema
4X/IP66 Door Assy
Includes Bezel, Touch
Screen and Door Assy
9 50015106 -501 QXe Nema 4X/IP66 Door
16 50015135-501 QXe Bezel/Touch Screen/Display As-
sembly NEMA 4X/IP66
Includes Bezel Touch
Screen Assy, Door,
Display, Speaker, In-
verter, Cables and
Mounting Bracket
19 50012893-501 QXe 5” Display with cables
23 50001782-501 QXe/QX/SX Speaker
24 50012896-501 QXe Case and Back Plate Assy
27 50015474-501 QXe Back Plate
28 50006787-501 QXe/QX/SX Battery (Kit of 5) Not shown
43 50012896-502 QXe Case, Handle and Terminal Cover Not shown
44 50012915-501 QXe Rear Terminal Cover Not shown
45 50020664-501 QXe Left & Right Hand Chassis kit
