43-TV-25-30 Iss.6 GLO Aug 07 UK 265
Firmware Options
Math Algorithms (optional) All analog input channels have a math expression text block. This is a fully user programmable 100 char-
acter free form math expression for each pen. Math calculations available on all pens, one per input plus
16 extra pens for the QX
, 48 extra pens for the SX recorder. and 12 extra pens for the QXe. Scripting
maths includes conditions and multi-line scripting in pen maths expressions. Allow functions, permanent
variables, constants and timers. 500 characters maximum. (Scripting is not available on the QXe
)
Events (optional) Events are certain conditions or operations that can be set up and logged according to the time and date
of an occurrence. Subsequently events can be reviewed or displayed on a graph. The Event Causes
include: Alarms - Into/Out of and Alarm Ack, Totals - Start/Stop/Reset/Reset and Start, Digital Input - ON/
OFF/State Change, T/C Burnout, Scheduled - Once/Interval/Specific Days/Month End, User Counters,
Max/Mins - Reset, System - Power ON/Setup Change/Internal Memory Low/Export Memory Low/FTP
Memory Low, User Action - Mark Chart, Batch - Start/Stop/Pause. The Event Effects include: Mark
Chart, Logging - Start/Stop, Totaliser - Start/Stop/Reset/Reset & Start, Digital Output - ON/OFF, Alarm
Acknowledge, Emails, Screen Change, Print Screen, Counters - Reset/Increment, Max/Min (Reset), Chart
Control - Pause/Stop/Resume/Clear/Prefil, Clear All Messages, Delayed Event, Script Timers - Start/Stop/
Reset/Reset & Start, Play Sound - Start/Stop, Display Alert, Reports, Batch - Start/Stop/Pause. Each event
marker can be recorded for analysis using the TrendManager Software Suite.
Fast Scanning mode For fast processes, the scan rate and recording of the data can be set for up to 50 times per second
(20ms) for up to 8 inputs for the Minitrend QX and 16 inputs for the Multitrend SX.
Totaliser/Sterilisation*
(optional)
One totaliser per pen. Totaliser value must be assigned to a pen for display and storage. Multiple totalisa-
tions (Maths option) are possible with the use of extra pens (option). Reset may be manual or pro-
grammed (Event option). Totalisation values are ten digits plus exponent.
Each pen can be totalised according to the Fo or Po sterilisation* function at 250 °F (121.11°C). The
Standard Reference Temperature and Thermal Resistance (Z Value) are fully adjustable values of X, Y, W
and V. Start temp, Reference temp and Z factor are all user defined, allowing support for many different
types of sterilisation applications.
Custom Screens (optional)
(not available for the QXe
Provides the capability in the recorder to accept custom screen designs from the Screen Designer.
Reports Generate reports manually or using the event system to show daily/weekly/monthly Totals, Max/Mins,
Averages, Current Value. Messages, Message Lists - Alarm, System, Diagnostic, Security & User,
Counters, Digital Inputs, and Digital Outputs. Reports can be printed, e-mailed as an attachment or
exported to external media in RTF format.
Health Watch/Maintenance
Capability (optional)
The recorder keeps track of important “life actions” for improved diagnostics and preventative mainte-
nance notification. Including Powered On, Last powered On, Time On since power up, Total On time, Total
Off time, Longest Off time, Lithium cell life, Backlight life left at 100% brightness, Hi/Lo CJC value (Hi & Lo
temps), Analogue In last factory/user cal, Relay operations, last configuration change.
Print Support (optional) Enables the printer option to print from various Status screens using a basic USB standard PCL (Printer
Command Language) printer.
Batch/Groups The Batch function allows the user to segment portions of data for further analysis. The Batch function
manages sections of data. Concurrent batches are now associated with a group of pens. The pens within
each group will belong to the batch that is controlled by that group. Batches can be controlled through the
event system and batch markers are setup by the user and used to identify and analyse batches of data.
Supports up to 6 concurrent batches.
Counters User Counters can be set up and used as a part of the Events system to count an occurrence. Other
counters are available depending on hardware availability. Eg. Alarm, Event, Digital Input, Relay Output
and Pulse counters.
Modbus Master Modbus master enables the recorder to communicate with up to 32 Slave devices on both Ethernet and
RS485. The recorder itself can also act as a slave device while also being a master. Modbus master can
also be used in conjunction with OPC to enable the recorder to act as a communication bridge.
Remote Viewer/Remote Con-
trol Tool
Extends the user interface of the recorder onto the desktop PC. Providing full remote control of the
recorder launched from a web browser.
Email (optional) Setup email accounts to send the following: When an Alarm is triggered or an Email can be sent as a part
of an Event occurring, such as: Alarms - In/Out/Ack, Totaliser – Start, Stop or Reset, Digital Inputs – On,
Off or State change, TC Burnout – on a specific Analogue Input channel, Scheduled Events – Once, Inter-
val, Specific days, Month End.
Specification Options
