Honeywell Vigilon 4 loop User Manual

Message
associated with.. meaning.. ..possible action
NVM is read only NVM
(non volatile memory)on
backplane or MCB
User attempts to write to a hardware write protected
NVM
Remove the hardware write protect before
writing
Panel in/out of
commissioning mode
MCC / MCB
(main control card/board)
Commissioning mode switched ON/OFF. To manually switch commissioning mode use
the [test/eng] menu.
Panel Label Set up MCC / MCB
(main control card/board)
Panel label has been set from the menu. -
Panel powerup MCC / MCB
(main control card/board)
Software reset of system or there has been a manual
reset of card 0.
If an automatic reset has occurred then check
for system errors.
Pattern number x on
loop y channel x
LPC
(loop processor card)
Sensor has detected an interesting event eg fire/fault. -
Pointer corrupted at
card x
Any Card Software error. Software errors will activate a system reset.
Ignore single occurrence.
Record the event in the log book.
Pointer missing at
card x
Any Card Software error Software errors will cause a system reset.
Card fault should be ignored for single
occurrence.
Record the event in the log book.
Prefire number x on
loop y channel z
LPC
(loop processor card)
Pattern match less than a Fire. -
Printer lost/fitted
at card x number y on
loop z
MCC / MCB / DAC / MRC The external printer has not been seen and is ‘lost’. Check the connections to the printer. Also
check for paper jam in the printer mechanism.
Program memory
corrupted at card x
Any Card Checksum failure on FLASH at midnight. Clear and ignore single occurrence.
Record in the log book.
Commissioning instructions
132 4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms.
Appendix B - Message Action List
