Configuration Menu 122
The commands in this menu configure VLAN attributes, change the status of the VLAN, delete the VLAN, and change
the port membership of the VLAN.
By default, the VLAN menu option is disabled except VLAN 1, which is always enabled. The GbE2c supports a
maximum of 1,000 VLANs. VLAN 4095 is reserved for switch management.
NOTE: See the HP GbE2c Ethernet Blade Switch for c-Class BladeSystem Application Guide for information on
VLANs.
The following table describes the VLAN Configuration Menu options.
Table 120 VLAN Configuration Menu options
Command Description
name <1-32 characters> Assigns a name to the VLAN or changes the existing name. The default
VLAN name is the first one.
stg <1-32> Assigns a VLAN to a spanning tree group.
add <port number> Adds ports to the VLAN membership.
rem <port number> Removes ports from the VLAN membership.
def <list of port numbers> Defines which ports are members of this VLAN. Every port must be a
member of at least one VLAN. By default, it defines ports to VLAN 1.
ena
Enables this VLAN.
dis Disables this VLAN without removing it from the configuration.
del Deletes this VLAN.
cur Displays the current VLAN configuration.
IMPORTANT: All ports must belong to at least one VLAN. Any port which is removed from a VLAN and which
is not a member of any other VLAN is automatically added to default VLAN #1. You cannot remove a port
from VLAN #1 if the port has no membership in any other VLAN. Also, you cannot add a port to more than
one VLAN unless the port has VLAN tagging turned on. See the tag command, in the “Port configuration”
section earlier in this chapter.
Layer 3 configuration
Command: /cfg/l3
[Layer 3 Menu]
if - Interface Menu
gw - Default Gateway Menu
route - Static Route Menu
arp - ARP Menu
frwd - Forwarding Menu
nwf - Network Filters Menu
rmap - Route Map Menu
rip - Routing Information Protocol Menu
ospf - Open Shortest Path First (OSPF) Menu
igmp - IGMP Menu
dns - Domain Name System Menu
bootp - Bootstrap Protocol Relay Menu
vrrp - Virtual Router Redundancy Protocol Menu
cur - Display current IP configuration
The following table describes the Layer 3 Configuration Menu options.
Table 121 L3 Configuration Menu options
Command Description
if <1-256>
Displays the IP Interface Menu.
gw <1-4>
Displays the IP Default Gateway Menu.
*route Displays the IP Static Route Menu.
arp
Displays the ARP (Address Resolution Protocol) Menu.
