Information Menu 35
LACP dump
Command: /info/l2/lacp/dump
>> LACP# dump
port lacp adminkey operkey selected prio attached trunk
aggr
----------------------------------------------------------------------
1 off 1 1 n 32768 -- --
2 off 2 2 n 32768 -- --
3 off 3 3 n 32768 -- --
4 off 4 4 n 32768 -- --
5 off 5 5 n 32768 -- --
6 off 6 6 n 32768 -- --
7 off 7 7 n 32768 -- --
8 off 8 8 n 32768 -- --
…
LACP dump includes the following information for each port in the GbE2c:
• lacp—Displays the port’s LACP mode (active, passive, or off)
• adminkey—Displays the value of the port’s adminkey.
• operkey—Shows the value of the port’s operational key.
• selected—Indicates whether the port has been selected to be part of a Link Aggregation Group.
• prio—Shows the value of the port priority.
• attached aggr—Displays the aggregator associated with each port.
• trunk—This value represents the LACP trunk group number.
