Information Menu 39
Table 22 STP parameters
Parameter Description
Designated port The port ID of the port on the Designated Bridge to which this port is connected. This
information includes the port priority (hex) and the port number (hex).
Rapid Spanning Tree and Multiple Spanning Tree information
Command: /info/l2/stp
------------------------------------------------------------------
upfast disabled, update 40
------------------------------------------------------------------
Spanning Tree Group 1: On (RSTP)
VLANs: 1-3 4095
Current Root: Path-Cost Port Hello MaxAge FwdDel
8000 00:00:01:00:19:00 0 0 9 20 15
Parameters: Priority Hello MaxAge FwdDel Aging
32768 9 20 15 300
Port Prio Cost State Role Designated Bridge Des Port Type
---- ---- ---- ------ ---- --------------------- -------- ----
1 0 0 DSB
2 0 0 DSB
3 0 0 DSB
4 0 0 DSB
5 0 0 DSB
6 0 0 DSB
7 0 0 DSB
8 0 0 DSB
9 0 0 DSB
10 0 0 DISC
11 0 0 FWD DESG 8000-00:00:01:00:19:00 8017 P2P2,Edge
12 0 0 FWD DESG 8000-00:00:01:00:19:00 8018 P2P
The switch software can be set to use the IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) or the IEEE 802.1s
Multiple Spanning Tree Protocol (MSTP). If RSTP/MSTP is turned on, you can view the following RSTP bridge
information for the Spanning Tree Group:
• Status of Uplink Fast (upfast)
• Current root MAC address
• Path-Cost
• Port
• Hello interval
• Maximum age value
• Forwarding delay
• Aging time
You can also refer to the following port-specific RSTP information:
• Port number and priority
• Cost
• State
• Role
• Designated bridge and port
• Link type
