Configuration Menu 123
Table 121 L3 Configuration Menu options
Command Description
*frwd Displays the IP Forwarding Menu.
*nwf <1-256>
Displays the Network Filter Configuration Menu.
*rmap <1-32>
Displays the Route Map Menu.
*rip
Displays the Routing Interface Protocol Menu.
*ospf
Displays the OSPF Menu.
igmp
Displays the IGMP Menu.
dns
Displays the IP Domain Name System Menu.
*bootp
Displays the Bootstrap Protocol Menu.
*vrrp
Displays the Virtual Router Redundancy Configuration Menu.
cur Displays the current IP configuration.
* indicates menus that are available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
IP interface configuration
Command: /cfg/l3/if <1-256>
[IP Interface 1 Menu]
addr - Set IP address
mask - Set subnet mask
vlan - Set VLAN number
ena - Enable IP interface
dis - Disable IP interface
del - Delete IP interface
cur - Display current interface configuration
The switch can be configured with up to 256 IP interfaces. Each IP interface represents the switch on an IP subnet on
your network. The IP Interface option is disabled by default.
The following table describes the IP Interface Configuration Menu options.
Table 122 IP Interface Configuration Menu options
Command Description
addr <IP address> Configures the IP address of the switch interface, using dotted decimal notation. For
example, 192.2.14.101
mask <IP subnet mask> Configures the IP subnet address mask for the interface using dotted decimal
notation. For example, 255.255.255.0
vlan <1-4095> Configures the VLAN number for this interface. Each interface can belong to one
VLAN, though any VLAN can have multiple IP interfaces in it.
ena Enables this IP interface.
dis Disables this IP interface.
del Removes this IP interface.
cur Displays the current interface settings.
NOTE: If you enter an IP address for interface 1, you are prompted to change the BOOTP setting.
