Information Menu 59
Logical Port to GEA Port mapping
Command: /info/geaport
Logical Port GEA Port(0-based) GEA Unit
------------ ----------------- ---------
1 1 0
2 2 0
3 4 0
4 7 0
5 8 0
6 12 0
7 13 0
8 14 0
9 0 0
10 3 0
11 5 0
12 6 0
13 9 0
14 10 0
15 11 0
16 15 0
17 16 0
18 17 0
19 18 0
20 19 0
21 23 0
22 22 0
23 21 0
24 20 0
This display correlates the logical port number to the GEA unit on which each port resides.
Uplink Failure Detection information
Command: /info/ufd
Uplink Failure Detection: Enabled
LtM status: Down
Member STG STG State Link Status
--------- --- ------------ -----------
port 24 down
1 DISABLED
10 DISABLED *
15 DISABLED *
* = STP turned off for this port.
LtD status: Auto Disabled
Member Link Status
--------- -----------
port 1 disabled
port 2 disabled
port 3 disabled
port 4 disabled
Uplink Failure Detection (UFD) information includes:
• UFD status, either enabled or disabled
• LtM status and member ports
• Spanning Tree status for LtM ports
• LtD status and member ports
