Configuration Menu 150
ACL Meter configuration
Command: /cfg/acl/acl <1-762>/meter
[Metering Menu]
cir - Set committed rate in KiloBits/s
mbsize - Set maximum burst size in KiloBits
enable - Enable/disable port metering
dpass - Set to Drop or Pass out of profile traffic
reset - Reset meter parameters
cur - Display current settings
This menu defines the metering profile for the selected ACL.
Table 164 ACL Meter Configuration Menu options
Command Description
cir <64-1000000>
Configures the committed rate, in Kilobits per second. The committed rate must
be a multiple of 64.
mbsize <32-4096>
Configures the maximum burst size, in Kilobits. Enter one of the following
values for mbsize: 32, 64, 128, 256, 512, 1024, 2048, 4096
enable e|d
Enables or disables metering on the ACL.
dpass drop|pass
Configures the ACL Meter to either drop or pass out-of-profile traffic.
reset
Reset ACL Metering parameters to their default values.
cur Displays the current ACL metering parameters.
ACL Re-mark configuration
Command: /cfg/acl/acl <1-762>/re-mark
[Re-mark Menu]
inprof - In Profile Menu
outprof - Out Profile Menu
reset - Reset re-mark settings
cur - Display current settings
You can choose to re-mark IP header data for the selected ACL. You can configure different remark values, based on
whether packets fall within the ACL Metering profile, or out of the ACL Metering profile.
Table 165 ACL Re-mark Configuration Menu options
Command Description
inprof
Displays the Re-mark In-Profile Menu.
outprof
Displays the Re-mark Out-of-Profile Menu.
reset
Reset ACL Re-mark parameters to their default values.
cur Displays the current ACL re-mark parameters.
