Configuration Menu 131
The following table describes the Open Shortest Path First Menu options.
Table 134 OSPF Configuration Menu options
Command Description
aindex <0-2>
Displays the area index menu. This area index does not represent the
actual OSPF area number.
range <1-16>
Displays summary routes menu for up to 16 IP addresses.
if <1-256>
Displays the OSPF interface configuration menu.
virt <1-3>
Displays the Virtual Links menu used to configure OSPF for a Virtual
Link.
md5key <1-255 characters>
Assigns a string to MD5 authentication key.
host <1-128>
Displays the menu for configuring OSPF for the host routes. Up to 128
host routes can be configured. Host routes are used for advertising
network device IP addresses to external networks to perform server load
balancing within OSPF. It also makes Area Border Route (ABR) load
sharing and ABR failover possible.
redist <fixed|static|rip>
Displays Route Distribution Menu.
lsdb <0-2000>
Sets the link state database limit. Enter 0 (zero) for no limit.
default <1-16777215> 1|2>|none
Sets one default route among multiple choices in an area.
Enter
none for no default route.
on
Enables OSPF.
off
Disables OSPF.
cur Displays the current OSPF configuration settings.
OSFP Area Index configuration
Command: /cfg/l3/ospf/aindex <0-2>
[OSPF Area (index) 1 Menu]
areaid - Set area ID
type - Set area type
metric - Set stub area metric
auth - Set authentication type
spf - Set time interval between two SPF calculations
enable - Enable area
disable - Disable area
delete - Delete area
cur - Display current OSPF area configuration
NOTE: This menu is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
