Configuration Menu
Introduction
The Configuration Menu is only available from an administrator login. It includes submenus for configuring every
aspect of the switch. Changes to configuration are not active until explicitly applied. Changes can be saved to non-
volatile memory (NVRAM).
Menu information
Command: /cfg
[Configuration Menu]
sys - System-wide Parameter Menu
port - Port Menu
l2 - Layer 2 Menu
l3 - Layer 3 Menu
qos - QOS Menu
acl - Access Control List Menu
rmon - RMON Menu
pmirr - Port Mirroring Menu
ufd - Uplink Failure Detection Menu
dump - Dump current configuration to script file
ptcfg - Backup current configuration to FTP/TFTP server
gtcfg - Restore current configuration from FTP/TFTP server
cur - Display current configuration
The following table describes the Configuration Menu options.
Table 77 Configuration Menu options
Command Usage
sys Displays the System Configuration Menu.
port <port number> Displays the Port Configuration Menu.
l2 Displays the Layer 2 Configuration Menu.
l3 Displays the Layer 3 Configuration Menu.
qos Displays the Quality of Service Configuration Menu.
acl Displays the Access Control List Configuration Menu.
rmon Displays the RMON Configuration Menu.
pmirr Displays the Mirroring Configuration Menu.
ufd Displays the Uplink Failure Detection Configuration Menu.
dump Dumps current configuration to a script file.
ptcfg <host name or IP address of
FTP/TFTP server> <filename on host>
Backs up current configuration to FTP/TFTP server.
gtcfg <host name or IP address of
FTP/TFTP server> <filename on host>
Restores current configuration from FTP/TFTP server.
cur Displays the current configuration parameters.
