Configuration Menu 147
[ACL Menu]
acl - Access Control List Item Config Menu
group - Access Control List Group Config Menu
cur - Display current ACL configuration
Use this menu to create Access Control Lists (ACLs) and ACL Groups. ACLs define matching criteria used for IP
filtering and Quality of Service functions.
The following table describes the Access Control Configuration Menu options.
Table 159 Access Control Configuration Menu options
Command Description
acl <1-762>
Displays Access Control List (ACL) configuration menu.
group <1-762>
Displays ACL Group configuration menu.
cur Displays the current Access Control parameters.
Access Control List configuration
Command: /cfg/acl/acl <1-762>
[ACL 1 Menu]
ethernet - Ethernet Header Options Menu
ipv4 - IP Header Options Menu
tcpudp - TCP/UDP Header Options Menu
meter - ACL Metering Configuration Menu
re-mark - ACL Re-mark Configuration Menu
pktfmt - Set to filter specific packet format types
egrport - Set to filter for packets egressing this port
action - Set filter action
stats - Enable/disable statistics for this acl
reset - Reset filtering parameters
cur - Display current filter configuration
These menus allow you to define filtering criteria for each Access Control List (ACL). The following table describes the
ACL Configuration Menu options.
Table 160 ACL Configuration Menu options
Command Description
ethernet
Displays the ACL Ethernet configuration menu.
ipv4
Displays the ACL IP version 4 configuration menu.
tcpudp
Displays the ACL TCP/UDP configuration menu.
meter
Displays the ACL meter configuration menu.
re-mark
Displays the ACL re-mark configuration menu.
pktfmt
Displays the ACL Packet Format configuration menu.
egrport <port number>
Configures the ACL to function on egress packets.
The egress port ACL will not match a Layer 2 broadcast or multicast
packet. The egress port ACL will not match packets if the destination port
is a trunk.
action permit|deny|setprio <0-7>
Configures a filter action for packets that match the ACL definitions. You
can choose to permit (pass) or deny (drop) packets, or set the 802.1p
priority for the packets.
stats e|d
Enables or disables the statistics collection for the Access Control List.
reset
Resets the ACL parameters to their default values and removes the ACL
from all ports to which it is assigned.
cur Displays the current ACL parameters.
