Configuration Menu 148
ACL Ethernet Filter configuration
Command: /cfg/acl/acl <1-762>/ethernet
[Filtering Ethernet Menu]
smac - Set to filter on source MAC
dmac - Set to filter on destination MAC
vlan - Set to filter on VLAN ID
etype - Set to filter on ethernet type
pri - Set to filter on priority
reset - Reset all fields
cur - Display current parameters
This menu allows you to define Ethernet matching criteria for an ACL. The following table describes the Ethernet Filter
Configuration Menu options.
Table 161 Ethernet Filter Configuration Menu options
Command Description
smac <MAC address> <MAC mask>
Defines the source MAC address and MAC mask for this ACL.
For example:
00:60:cf:40:56:00 ff:ff:ff:ff:ff:fc
dmac <MAC address> <MAC mask>
Defines the destination MAC address and MAC mask for this
ACL. For example:
00:60:cf:40:56:00 ff:ff:ff:ff:ff:fc
vlan <1-4095> <VLAN mask (0xfff)>
Defines a VLAN number and mask for this ACL.
etype ARP|IP|IPv6|MPLS|RARP|any|0xXXXX
Defines the Ethernet type for this ACL.
pri <0-7>
Defines the Ethernet priority value for the ACL.
reset
Resets Ethernet parameters for the ACL to their default values.
cur Displays the current Ethernet parameters for the ACL.
ACL IP Version 4 Filter configuration
Command: /cfg/acl/acl <1-762>/ipv4
[Filtering IPv4 Menu]
sip - Set to filter on source IP address
dip - Set to filter on destination IP address
proto - Set to filter on protocol
tos - Set to filter on TOS
reset - Reset all fields
cur - Display current parameters
This menu allows you to define IPv4 matching criteria for an ACL. The following table describes the IP version 4 Filter
Configuration Menu options.
Table 162 IPv4 Filter Configuration Menu options
Command Description
sip <IP address> <IP mask>
Defines a source IP address for the ACL. If defined, traffic with this source IP
address will match this ACL. Specify an IP address in dotted decimal notation.
For example, 100.10.1.1
dip <IP address> <IP mask>
Defines a destination IP address for the ACL. If defined, traffic with this
destination IP address will match this ACL. For example, 100.10.1.2
