Configuring the switch 132
Table 101 Switch Port Configuration controls
Control Description
PVID Tagging Disables or enables VLAN tag persistence. When disabled, the VLAN tag
is removed from packets whose VLAN tag matches the port PVID. The
default value is enabled.
Port STP Turns Spanning Tree On or Off for this port.
Default Port VLAN ID (1-4095) Sets the default VLAN number which will be used to forward frames
which are not VLAN tagged.
The default number is 1.
Note: VLAN 4095 is reserved for switch management.
Flow Control Sets the flow control. The choices include:
• Receive flow control
• Transmit flow control
• Both receive and transmit flow control (default)
• No flow control
Autonegotiation Enables or disables auto negotiation for the port.
Speed Sets the link speed. Not all options are valid on all ports. The choices
include:
• “Any,” for automatic detection (default)
• 10 Mbps
• 100 Mbps
• 1000 Mbps
Duplex mode Sets the operating mode. Not all options are valid on all ports. The
choices include:
• “Any,” for auto negotiation (default)
• Full-duplex
• Half-duplex
Enable/Disable sending Link UP/Down Trap Enables or disables the sending of SNMP link up and link down traps.
The default setting is enabled.
Port Name Sets a name for the port. The assigned port name appears next to the
port number on some information and statistics screens.
Multicast Threshold Enables or disables multicast threshold limit.
Limits the number of multicast packets to the specified value. If disabled
(
dis), the port forwards all multicast packets.
Multicast Threshold Rate (0-262143) Configures the threshold rate for multicast packets, in packets per second.
Broadcast Threshold Enables or disables broadcast threshold limit.
Limits the number of broadcast packets to the specified value. If disabled
(
dis), the port forwards all broadcast packets.
Broadcast Threshold Rate (0-262143) Configures the threshold rate for broadcast packets, in packets per
second.
Destination Look Up Fail Threshold Enables or disables threshold limit for destination lookup failures.
Limits the number of unknown unicast packets to the specified value. If
disabled (
dis), the port forwards all unknown unicast packets.
Destination Lookup Fail Threshold Rate (0-
262143)
Configures the threshold rate for destination lookup failures, in packets
per second.
802.1p Port Priority (0-7) Configures the port’s 802.1p priority level.
