Configuring the switch 155
RMON Alarm Configuration Table
To display the following form, select RMON > Alarm (click the underlined text, not the folder).
The following table describes the Alarm Groups Configuration controls:
Table 124 RMON Alarm Configuration controls
Control Description
Search Range To search for a RMON Alarm, enter a range of numbers in the From and To fields.
Search Options To focus the search for a RMON Alarm, enter optional search parameters:
• MIB OID
• Interval
• Rising Limit
• Falling Limit
• Rising Event Index
• Falling Event Index
• Alarm Type
• Sample Type
Fields that have a value of “any” are ignored during the search.
Choose a search operation:
• or: Search for Alarms specified in the search range that meet any of the criteria entered.
• and: Search for Alarms specified in the search range that meet all of the criteria entered.
Click Search to display RMON Alarms that fit the range and meet the criteria entered.
