Configuring the switch 174
IGMP Filter Configuration
To display the following form, go to the IGMP Filters Configuration form. Select a Filter ID, or open the IGMP
Filters folder and click Add Filter.
The following table describes the IGMP Filter Configuration controls:
Table 142 IGMP Filter Configuration controls
Control Description
Filter Identifier (1 - 16) Selects an IGMP filter to configure.
Enabled? Enables or disables this IGMP filter.
Range 1 IP Multicast Address Configures the start of the range of IP multicast addresses for this filter.
Range 2 IP Multicast Address Configures the end of the range of IP multicast addresses for this filter.
Action Allows or denies multicast traffic for the IP multicast address range specified.
IGMP Filtering Port Configuration
To display the following form, select Layer 3 > IGMP > Switch Ports.
