Configuring the switch 159
IP Interfaces Configuration
To display the following form, select Layer 3 > IP Interfaces (click the underlined text, not the folder).
This form summarizes IP Interface parameters.
The following table describes IP Interfaces Configuration controls:
Table 128 IP Interfaces Configuration controls
Control Description
Search Range To search for an IP Interface, enter a range of IP Interface numbers in the From and To fields.
Search Options To focus the search for an IP Interface, enter optional search parameters:
• IP Address
• Subnet Mask
• VLAN ID number
• IP Interface State
Fields that have a value of “any” are ignored during the search.
Choose a search operation:
• or: Search for IP Interfaces specified in the Search range that meet any of the criteria entered.
• and: Search for IP Interfaces specified in the Search range that meet all of the criteria entered.
Click Search to display IP Interfaces that fit the range and meet the criteria entered.
