Dashboard 36
The following table describes the Switch LACP Dashboard controls:
Table 20 LACP Dashboard controls
Control Description
Switch Port Displays the port number.
LACP Mode Displays the port’s LACP mode (active, passive, or off).
LACP Adminkey Displays the value of the port’s adminkey.
LACP Operkey Displays the value of the port’s operkey.
LACP Selected Indicates whether the port has been selected to be part of a Link Aggregation
Group.
Port Priority Shows the value of the port priority.
Attached Aggr Displays the aggregator associated with each port.
Trunk Displays the value that represents the LACP trunk group number.
LACP Port Dashboard
To display the following form, go to the Switch LACP Dashboard. Select a port number.
This form summarizes LACP port information.
