HP GbE2c - Blc Layer 2/3 Fiber SFP Option User Manual

Configuring the switch 181
Table 148 OSPF Summary Range Configuration controls
Control Descriptions
Subnet Mask Defines the IP address mask for the range.
OSPF Interfaces Configuration
NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > OSPF Routing Protocol > OSPF Interfaces (click the underlined text,
not the folder).
This form provides a summary of the state of OSPF interfaces.
The following table describes OSPF Interfaces Configuration controls:
Table 149 OSPF Interfaces Configuration controls
Control Description
Search Operation To focus the search for an OSPF interface, enter search parameters:
• IP interfaces
• Area Number
• State
Fields that have a value of “any” are ignored during the search.
Choose a search operation:
• or: Search for OSPF interfaces specified in the Search range that meet any of the criteria
entered.
• and: Search for OSPF interfaces specified in the Search range that meet all of the criteria
entered.
Click Search to display OSPF interfaces that fit the range and meet the criteria entered.
