Switch Ports 802.1x Dashboard
To display the following form, select Layer 2 > 802.1x > Switch Ports.
The following table describes the Switch Ports 802.1x Dashboard fields:
Table 11 Switch Ports 802.1x Dashboard
Field Description
Port Displays each port’s name.
Auth Mode Displays the Access Control authorization mode for the port. The
Authorization mode can be one of the following:
• force-unauth
• auto
• force-auth
Auth Status Displays the current authorization status of the port, either authorized or
unauthorized.
Ctrl Dir Displays the controlled direction for the port, as follows:
• both: indicates that control is exerted over both incoming and
outgoing traffic through the controlled port.
• In: indicates that control is exerted only over incoming traffic through
the controlled port.
