Configuring the switch 142
The following table describes the Switch Spanning Tree Groups Configuration controls:
Table 111 Switch Spanning Tree Groups Configuration controls
Control Description
Search Range To search for a Spanning Tree Group, enter a range of group numbers in the From and To fields.
Search Options To focus the search for a Spanning Tree Group, enter optional search parameters:
• Bridge Priority
• Spanning Tree State
Fields that have a value of “any” are ignored during the search.
Choose a search operation:
• or: Search for Spanning Tree Groups specified in the search range that meet any of the criteria
entered.
• and: Search for Spanning Tree Groups specified in the search range that meet all of the criteria
entered.
Click Search to display Spanning Tree Groups that fit the range and meet the criteria entered.
Switch Spanning Tree Group Configuration
To display the following form, go to the Switch Spanning Tree Groups Configuration form. Select a Spanning
Tree Group number, or open the Spanning Tree Groups folder and click Add Spanning Tree Group.
Spanning Tree bridge parameters can be configured for each Spanning Tree Group.
