Configuring the switch 203
Table 170 Access Control List Configuration controls
Control Description
Ethernet Type Defines the Ethernet type for this ACL.
VLAN ID (1-4095) Defines a VLAN number and mask for this ACL.
802.1p Priority Defines the 802.1p priority for the ACL.
Type of Service (0-255) Defines a Type of Service value for the ACL. For more information on ToS, see RFC 1340
and 1349.
Protocol (0-255) Defines an IP protocol for the ACL. If defined, traffic from the specified protocol matches this
filter. Specify the protocol number. Listed below are some of the well-known protocols.
Number
Name
1 icmp
2 igmp
6 tcp
17 udp
89 ospf
112 vrrp
Source IP Address Defines a source IP address for the ACL. If defined, traffic with this source IP address will
match this ACL. Specify an IP address in dotted decimal notation.
Destination IP Address Defines a destination IP address for the ACL. If defined, traffic with this destination IP
address will match this ACL.
TCP/UDP Src Port (1-65535) Defines a source port for the ACL. If defined, traffic with the specified TCP or UDP source
port will match this ACL. Specify the port number. Listed below are some of the well-known
ports:
Number
Name
20 ftp-data
21 ftp
22 ssh
23 telnet
25 smtp
37 time
42 name
43 whois
53 domain
69 tftp
70 gopher
79 finger
80 http
TCP/UDP Dst Port (1-65535) Defines a destination port for the ACL. If defined, traffic with the specified TCP or UDP
destination port will match this ACL. Specify the port number, just as with
sport above.
TCP Flags Defines a TCP/UDP flag for the ACL.
Statistics Enables or disables the statistics collection for the ACL.
Egress Port Selects an egress port to add to the ACL.
The egress port ACL will not match a Layer 2 broadcast or multicast packet. The egress port
ACL will not match packets if the destination port is a trunk.
