HP ProCurve 6120G/XG Configuration Guide

Port Traffic Controls
Guaranteed Minimum Bandwidth (GMB)
ProCurve(config)# show bandwidth output a1-a5
Outbound Guaranteed Minimum Bandwidth %
Port Q1 Q2 Q3 Q4 Q5 Q6 Q7 Q8
---- -- -- -- -- -- -- -- -
-
A1 2 3 30 10 10 10 15 20
User-Configured
A2 2 3 30 10 10 10 15 20
Minimum
A3 2 3 30 10 10 10 15 20
Bandwidth
A4 2 3 30 10 10 10 15 20
Settings
A5 2 3 30 10 10 10 15 20
Figure 12-2. Example of Listing the Guaranteed Minimum Bandwidth
Configuration
This is how the preceding listing of the GMB configuration would appear in
the startup-config file.
Figure 12-3. Example of GMB Settings Listed in the “show config” Output
The outbound port
priority queues 1 - 8
for ports A1-A5 are
configured with the
indicated
Guaranteed
Minimum Bandwidth
percentages.
12-18
