ProCurve# show lldp info local-device
LLDP Local Device Information
Chassis Type : mac-address
Cha
ssis Id : 00 24 81 b0 09 21
System Name : ProCurve 6120 Blade Switch
System Description : ProCurve 498358-B21 6120 Blade Switch, revision ...
System Capabilities Supported:bridge
System Capabilities Enabled:bridge
The Management Address field displays only
Management Address :
the LLDP-configurable IP addresses on the
Type:ipv4
Address:16.93.40.251
switch. (Only manually-configured IP
addresses are LLDP-configurable.) If the
LLDP Port Information
switch has only an IP address from a DHCP or
Port | PortType PortId PortDesc
Bootp server, then the Management Address
-------- + -------- -------- --------
field is empty (because there are no LLDP-
D1 | local 1 D1
configurable IP addresses available). For more
D2 | local 2 D2
D3 | local 3 D3
on this topic, refer to “Remote Management
D4 | local 4 D4
Address” on page 13-46.
D5 | local 5 D5
D6 | local 6 D6
. . . .
. . . .
. . . .
Figure 13-25. Example of Displaying the Global and Per-Port Information Available for Outbound
Advertisements
Figure 13-26. Example of the Default Per-Port Information Content for Ports 1 and 2
Displaying the Current Port Speed and Duplex Configuration on a
Switch Port. Port speed and duplex information for a switch port and a
connected LLDP-MED endpoint can be compared for configuration
mismatches by using an SNMP application. You can also use the switch CLI
to display this information, if necessary. The following two commands provide
methods for displaying speed and duplex information for switch ports. For
information on displaying the currently configured port speed and duplex on
13-76
