HPE FlexFabric 5700 Series User Manual

127
Step Command Remarks
•
The probe-failure
consecutive-probe-failure
s option.
• The
ccumulate-probe-failures
argument.
5. Configure
threshold
monitoring.
• Monitor the operation duration (not
supported in the UDP jitter and voice
operations):
reaction item-number checked-element
probe-duration threshold-type
{ accumulate accumulate-occurrences |
average | consecutive
consecutive-occurrences }
threshold-value upper-threshold
lower-threshold [ action-type { none |
trap-only } ]
• Monitor failure times (not supported in the
UDP jitter and voice operations):
reaction item-number checked-element
probe-fail threshold-type { accumulate
accumulate-occurrences | consecutive
consecutive-occurrences } [ action-type
{ none | trap-only } ]
• Monitor the round-trip time (only for the in
UDP jitter and voice operations):
reaction item-number checked-element
rtt threshold-type { accumulate
accumulate-occurrences | average }
threshold-value upper-threshold
lower-threshold [ action-type { none |
trap-only } ]
• Monitor packet loss (only for the UDP jitter
and voice operations):
reaction item-number checked-element
packet-loss threshold-type accu
mulate
accumulate-occurrences [ action-type
{ none | trap-only } ]
• Monitor the one-way jitter (only for the
UDP jitter and voice operations):
reaction item-number checked-element
{ jitter-ds | jitter-sd } threshold-type
{ accumulate accumulate-occurrences |
average } threshold-value
upper-threshold lower-threshold
[ action-type { none | trap-only } ]
• Monitor the one-way delay (only for the
UDP jitter and voice operations):
reaction item-number checked-element
{ owd-ds | owd-sd } threshold-value
upper-threshold lower-threshold
• Monitor the ICPIF value (only for the voice
operation):
reaction item-number checked-element
icpif threshold-value upper-threshold
lower-threshold [ action-type { none |
trap-only } ]
• Monitor the MOS value (only for the voice
operation):
reaction item-number checked-element
mos threshold-value upper-threshold
N/A

HPE FlexFabric 5700 Series Specifications

General

Product Line	HPE FlexFabric
Model	5700 Series
Power Supply	Redundant power supply options
Layer Support	Layer 2/3
Management	HPE Intelligent Management Center (IMC), CLI, SNMP
Routing Protocol	RIP, OSPF, BGP, IS-IS
Features	Virtualization
Compliant Standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad, IEEE 802.3ae
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% (noncondensing)
Latency	Less than 1 µs
