HPE ProLiant MicroServer Gen10 Maintenance And Service Guide

3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 25.
5. Disconnect the SSD SATA cable.
6. Connect the new SSD SATA cable.
7. Install the chassis cover on page 28.
8. Connect all peripheral cables to the server.
9. Connect the power cord to the server power jack, and then to the AC source.
10. Power up the server on page 30.
Disconnect the SSD SATA cable
Procedure
1. Open the cable tie securing the SSD SATA cable.
2. Disconnect the SATA cable from the SATA connector, and then pull the cable out of the left side
chassis opening.
3. Disconnect the SATA cable from the SSD.
Disconnect the SSD SATA cable 45

HPE ProLiant MicroServer Gen10 Specifications

General

Product Line	HPE ProLiant
Server Type	MicroServer
Maximum Memory	32 GB
Memory Slots	2
Expansion Slots	1 PCIe 3.0 x8 slot
Form Factor	Ultra Micro Tower
Processor	AMD Opteron X3000 series
Memory Type	DDR4 ECC UDIMM
Storage	4 LFF non-hot plug drive bays
Network	2 x 1GbE ports
Power Supply	200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions	23.5 x 23 x 25.4 cm
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Management	HPE iLO Standard
RAID Support	HPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
