4. Remove the chassis cover on page 25.
5. Remove the system board assembly on page 25.
6. Replace the system battery on page 66.
7. Install the system board assembly on page 27.
8. Install the chassis cover on page 28.
9. Connect all peripheral cables to the server.
10. Connect the power cord to the server power jack, and then to the AC source.
11. Power up the server on page 30.
Replace the system battery
Procedure
1. Locate the battery on the system board.
2. Slightly push the metal tab, and then remove the system battery from its socket.
3. Slightly push the metal lab, and then install the new system battery in the socket.
66 Replace the system battery
