Chapter 3 Connection Status and System Info
B222s User’s Guide
32
Firmware Version This field displays the current version of the firmware inside the device. It also
shows the date the firmware version was created. Go to the Maintenance >
Firmware Upgrade screen to change it.
WAN Information
Mode This is the method of encapsulation used by your ISP.
IP Address This field displays the current IP address of the LTE Device in the WAN.
LAN Information
IP Address This field displays the current IP address of the LTE Device in the LAN.
IP Subnet Mask This field displays the current subnet mask in the LAN.
DHCP Server This field displays what DHCP services the LTE Device is providing to the LAN.
Choices are:
Server - The LTE Device is a DHCP server in the LAN. It assigns IP addresses to
other computers in the LAN.
None - The LTE Device is not providing any DHCP services to the LAN.
WLAN Information
Channel This is the channel number used by the LTE Device now.
WPS Status Configured displays when a wireless client has connected to the LTE Device or
WPS is enabled and wireless or wireless security settings have been configured.
Unconfigured displays if WPS is disabled or wireless security settings have not
been configured.
SSID (1~4) Information
SSID This is the descriptive name used to identify the LTE Device in the wireless LAN.
Status This shows whether or not the SSID is enabled (on).
Security Mode This displays the type of security the LTE Device is using in the wireless LAN.
LTE Status
Status This displays 4G LTE if there is an LTE connection, otherwise, it displays N/A.
Signal Strength This displays the strength of the LTE connection that the LTE Device has with the
base station which is also known as eNodeB or eNB.
Service Provider This displays the service provider’s name of the connected LTE network.
Frequency Band This displays LTE if there is an LTE connection.
Connection Uptime This displays how long the LTE connection has been available since it was last
established successfully.
ODU F/W Version This displays the firmware version of the outdoor unit.
Module F/W Version This displays the firmware version of LTE module.
IMEI This displays the LTE Device’s International Mobile Equipment Identity number
(IMEI). An IMEI is a unique ID used to identify a mobile device.
IMSI This displays the International Mobile Subscriber Identity (IMSI) of the SIM card
inserted in the outdoor unit. An IMSI is a unique ID used to identify a mobile
subscriber in a mobile network.
Interface Status
Interface This column displays each interface the LTE Device has.
Table 3 System Info Screen (continued)
LABEL DESCRIPTION
