Figure 8-9 AC surge protection box installed on a wood pole
8.3 Installing an AC Surge Protection Box
This section describes the procedure for installing an AC surge protection box.
Procedure
l Install an AC surge protection box on a pole, as shown in Figure 8-10.
NOTE
l When the diameter of the pole ranges from 60 mm to 114 mm (2.36 in. to 4.49 in.), the hose clamps
delivered with the AC surge protection box is used.
l When the diameter of the pole ranges from 114 mm to 400 mm (4.49 in. to 15.75 in.), the hose clamps
purchased locally is used.
Figure 8-10 Installing the AC surge protection box on a pole
8 Installing an AC Surge Protection Box and Related Cables
BTS3902E WCDMA
Installation Guide
8-6 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue Draft A (2011-06-30)
