Parameter IPC6231-WD-VRZ
3 Megapixel CMOS WDR
Network Bullet Camera
Matched Criterion Protection Criterion
1: Ports matched criterion
(TVS±2000V)
2:CE EMC test criterion
(EN55022, EN50130-4)
Ingress Protection level IP66
Physical parameters Net Weight 1400g
Weight with package 1700g
Dimensions (mm) 98.0×105.0×328.8
Packaged Size (mm) 386×156×155
14.2 Specification of IPC6232-IR
Table 14-2 Specification of IPC6232 Series
Parameter IPC6232-IR
3 Megapixel Bullet
Network Camera
Camera Image Sensor 1/3" Progressive Scan
CMOS
Max. Resolution 2048 (H)×1536 (V)
Min. Illumination 0.07 Lux @ (F1.2,AGC ON),
0 Lux with IR
0.1Lux @ (F1.4,AGC ON), 0
Lux with IR
Digital Noise Reduction 52dB
Shutter Speed 1s ~ 1/100,000s
IR Range Approx.20 to 30 meters
Lens Len Type Φ14, DC drive auto-iris
Lens 4mm fixed focus
Operating Environment Power Supply 12 VDC±10%/PoE (802.3af)
IPC6131-WD-A&6123-WDL-A&6232-IR&6212-
IR&6231-WD-VRZ&6332-MIR&6311-IR&6331-IR
