Parameter IPC6232-IR
3 Megapixel Bullet
Network Camera
Humidity 5%~90% (non-condensing)
Power Consumption Max.5.5W (Max.7.5W with
IR cut filter on)
Matched Criterion Protection Criterion
1:Ports matched criterion
(TVS±2000V)
2:CE EMC test criterion
(EN55022, EN50130-4)
Ingress Protection Level IP66
Vandal-proof Level IEC60068-2-75 test, Eh, 50J;
EN50102, IK10
Physical parameters Net Weight 1000
Weight with package 1200
Dimensions (mm) 98.0×105.0×328.8
Packaged Size (mm) 386×156×155
14.3 Specification of IPC6212-IR
Table 14-3 Specification of IPC6212 Series
Parameter IPC6212-IR
1.3 Megapixel Bullet
Network Camera
Camera Image Sensor 1/3" Progressive Scan
CMOS
Max. Resolution 1280 (H)×960 (V)
Min. Illumination 0.01Lux @ (F1.2,AGC ON),
0 Lux with IR
0.014Lux @ (F1.4,AGC
ON), 0 Lux with IR
Digital Noise Reduction 52dB
Shutter Speed 1s ~ 1/100,000s
IPC6131-WD-A&6123-WDL-A&6232-IR&6212-
IR&6231-WD-VRZ&6332-MIR&6311-IR&6331-IR
