NetCol5000-A 42 kW Air Cooled In-row Precision Air
Conditioner
User Manual
5 Operation and Maintenance
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Procedure
Step 1 On the controller home screen, tap Shutdown, and turn off the air conditioner switch in the
PDC.
Exercise caution because the device is still energized after it is shut down on the controller
home screen.
Step 2 Open the front door, and disconnect the white power cable terminals of the condensate pump
at the lower right corner of the cabinet.
Figure 5-31 Disconnecting the power cable terminals
Step 3 Remove the condensate pump assembly, as shown in Figure 5-32.
