NetCol5000-A 42 kW Air Cooled In-row Precision Air
Conditioner
User Manual
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 3-26 Routing the refrigerant pipe
Onsite personnel are responsible for preparing the required materials and installing the supports.
Bottom Pipe Routing
Step 1 Remove the plugs from the bottom refrigerant pipe using a welding torque, as shown in
Figure 3-27.
Figure 3-27 Bottom pipe routing
