3.3.1 System Air Channel
The system air channel allows air to
ow from front to back or from back to front.
Figure 3-28 Front to back (NetEngine 8000 F1A as an example)
Figure 3-29 Back to front (NetEngine 8000 F1A as an example)
3.3.2 NetEngine 8000 F1A-8H20Q Fan Module
3.3.2.1 FAN-031A-B (Fan box(B,FAN panel side exhaust))
Overview
Table 3-72 Basic information about the FAN-031A-B
Item
Details
Description Fan box(B,FAN panel side exhaust)
Part Number 02352CAB
Model FAN-031A-B
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 89
