corresponds to that of the original Optical Module, as the following
output in bold displays:
<HUAWEI> display interface Gigabitethernet0/1/0
GigabitEthernet0/1/0 current state : DOWN
Line protocol current state : DOWN
Description: HUAWEI, GigabitEthernet0/1/0 Interface (index: 7)
Route Port,The Maximum Transmit Unit is 1500
IP Sending Frames' Format is PKTFMT_ETHNT_2, Hardware address is 001a-2b11-4d51
The Vendor PN is RTXM191-400
The Vendor Name is WTD
Port BW: 1G, Transceiver max BW: 1G, Transceiver Mode: SingleMode
WaveLength: 1310nm, Transmission Distance: 10km
Rx Power: -1.43dBm, normal range: [-19.014, -3.000]dBm
Tx Power: -4.86dBm, normal range: [-6.859, -2.857]dBm
Loopback:none, full-duplex mode, negotiation: disable, Pause Flowcontrol:Receive Enable
and Send Enable
Last physical up time : 2012-10-11 10:01:20
Last physical down time : 2012-10-11 10:01:19
Current system time: 2012-10-12 09:53:44
Statistics last cleared:2012-10-12 09:02:03
Last 300 seconds input rate: 0 bits/sec, 0 packets/sec
Last 300 seconds output rate: 0 bits/sec, 0 packets/sec
Input peak rate 88 bits/sec, Record time: 2012-10-12 09:03:45
Output peak rate 78 bits/sec, Record time: 2012-10-12 09:02:54
Input: 2144 bytes, 22 packets
Output: 614 bytes, 7 packets
Input:
Unicast: 21 packets, Multicast: 1 packets
Broadcast: 0 packets, JumboOctets: 0 packets
CRC: 0 packets, Symbol: 0 packets
Overrun: 0 packets, InRangeLength: 0 packets
LongPacket: 0 packets, Jabber: 0 packets, Alignment: 0 packets
Fragment: 0 packets, Undersized Frame: 0 packets
RxPause: 0 packets
Output:
Unicast: 6 packets, Multicast: 1 packets
Broadcast: 0 packets, JumboOctets: 0 packets
Lost: 0 packets,
Overow: 0 packets, Underrun: 0 packets
System: 0 packets, Overruns: 0 packets
TxPause: 0 packets
Last 300 seconds input utility rate: 0.00%
Last 300 seconds output utility rate: 0.00%
– Check whether there is any new alarm or performance event.
– Check whether the services are normal on the new Optical Module. If the
services are normal, it indicates that replacing an Optical Module is
successful.
If the new Optical Module fails to return to the normal state, you should
contact a Huawei local
oce for timely technical support.
Follow-up Procedure
After replacing an Optical Module, collect the tools. If an Optical Module that is
replaced and is
conrmed to be faulty, you should ll in the Osite Repair Card
for Faulty Materials, and send the card and the faulty Optical Module to a Huawei
local oce for timely maintenance.
4.2.11.5 Replacing an Optical Cable
Context
Before replacing an optical cable, you need to note the owing points:
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 636
