3.4.7.7 0.1~1.25Gbps-eSFP-SMF-1310nm(Tx)/1550nm(Rx)-40km-commercial
Table 3-120 0.1~1.25Gbps-eSFP-SMF-1310nm(Tx)/1550nm(Rx)-40km-commercial
specications
Item Value
Basic Information
Module name 0.1~1.25Gbps-eSFP-SMF-1310nm(Tx)/
1550nm(Rx)-40km-commercial
Part Number 34060638
Model eSFP-1310/1550-L1.1-BIDI
Form factor eSFP
Application standard IEEE 802.3ah, 1000Base-BX40-U
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] -5°C to 70°C(23°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 0.1~1.25 Gbit/s
Target transmission distance [km] 40 km
Transmitter Optical Characteristics
Center wavelength [nm] 1310 nm
Tx operating wavelength range [nm] 1260 nm - 1360 nm
Maximum Tx optical power (AVG)
[dBm]
2 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-3 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 9 dB
