Item Value
Maximum Tx optical power (AVG)
[dBm]
per lane: 0.5 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
per lane: -8.2 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1260 nm - 1355 nm
Rx sensitivity (AVG) [dBm] -
Rx sensitivity (OMA) [dBm] per lane: -12.6 dBm
Overload power (AVG) [dBm] per lane: 0.5 dBm
Overload power (OMA) [dBm] -
3.4.16.4 QSFP-40G-LX4-MM (02313NUG)
Table 3-200 QSFP-40G-LX4-MM
specications
Item
Value
Basic Information
Module name QSFP-40G-LX4-MM
Part Number 02313NUG
Model QSFP-40G-LX4-MM
Form factor QSFP+
Application standard 40GBASE-LX4
Connector type LC
Optical ber type MMF
Working case temperature [°C(°F)] 0°C to 70°C (32°F to 158°F)
Transmission rate [bit/s] 40Gbit/s
Target transmission distance [km] 150m
Transmitter Optical Characteristics
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 259
