Item Value
Overload power (AVG) [dBm] per lane: 4.5 dBm
Overload power (OMA) [dBm] -
NOTE
The optical power calculation is based on the OMA value. The optical power read by the
device is the average optical power, not the OMA optical power.
3.4.19.5 100Gbps(4*25.7)-QSFP28-SMF-1295.56~1309.14nm-80km-
commercial
Table 3-213 100Gbps(4*25.7)-QSFP28-SMF-1295.56~1309.14nm-80km-
commercial
specications
Item Value
Basic Information
Module name 100Gbps(4*25.7)-QSFP28-
SMF-1295.56~1309.14nm-80km-
commercial
Part Number 02312NCX
Model QSFP28-100G-1310nm-80km-SM-01
Form factor QSFP28
Application standard Huawei Dene
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 103.125 Gbit/s
Target transmission distance [km] 80 km
Transmitter Optical Characteristics
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 279
