Item Value
NOTE
1. If the module needs to reach the nominal data, the board FEC function must be enabled.
2. The optical power calculation is based on the OMA value.
3. The optical module can be connected only to the optical module with the same BOM
number.
3.4.18 50Gbps QSFP28 BIDI Optical Module
3.4.18.1 50Gbps-QSFP28-SMF-1331nm(Tx)/1271nm(Rx)-10km-commercial
Table 3-205 50Gbps-QSFP28-SMF-1331nm(Tx)/1271nm(Rx)-10km-commercial
specications
Item Value
Basic Information
Module name 50Gbps-QSFP28-SMF-1331nm(Tx)/
1271nm(Rx)-10km-commercial
Part Number 02312EVV
Model QSFP28-50G-BIDI-10km-SM-1
Form factor QSFP28
Application standard IEEE 802.3bm-2015, 50GBASE-BR10
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12(after FEC)
<2x10E-4(before FEC)
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 53.125 Gbit/s
Target transmission distance [km] 10 km
Transmitter Optical Characteristics
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 266
