3.4.7.4 1.25Gbps-eSFP-SMF-1490nm(Tx)/1310nm(Rx)-40km-commercial
Table 3-117 1.25Gbps-eSFP-SMF-1490nm(Tx)/1310nm(Rx)-40km-commercial
specications
Item Value
Basic Information
Module name 1.25Gbps-eSFP-SMF-1490nm(Tx)/
1310nm(Rx)-40km-commercial
Part Number 34060540
Model OGEBIDI40
Form factor eSFP
Application standard IEEE 802.3ah, 1000Base-BX40-D
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 1.25 Gbit/s
Target transmission distance [km] 40 km
Transmitter Optical Characteristics
Center wavelength [nm] 1490 nm
Tx operating wavelength range [nm] 1480 nm - 1500 nm
Maximum Tx optical power (AVG)
[dBm]
3 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-2 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 9 dB
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 152
