Huawei NetEngine 8000 F

Item Value
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 1.25 Gbit/s
Target transmission distance [km] 40 km
Transmitter Optical Characteristics
Center wavelength [nm] 1310 nm
Tx operating wavelength range [nm] 1260 nm - 1360 nm
Maximum Tx optical power (AVG)
[dBm]
3 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-2 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 9 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1480 nm - 1500 nm
Rx sensitivity (AVG) [dBm] -
Rx sensitivity (OMA) [dBm] -23 dBm
Overload power (AVG) [dBm] -3 dBm
Overload power (OMA) [dBm] -
NOTE
Used in pair with 34060540.
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 151
