Item Value
Transmitter Optical Characteristics
Center wavelength [nm] 1570 nm
Tx operating wavelength range [nm] 1560 nm - 1580 nm
Maximum Tx optical power (AVG)
[dBm]
4 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-2 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 9 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1480 nm - 1500 nm
Rx sensitivity (AVG) [dBm] -26 dBm
Rx sensitivity (OMA) [dBm] -
Overload power (AVG) [dBm] -3 dBm
Overload power (OMA) [dBm] -
NOTE
Used in pair with 34060596.
3.4.7.6 1.25Gbps-eSFP-SMF-1490nm(Tx)/1570nm(Rx)-80km-commercial
Table 3-119 1.25Gbps-eSFP-SMF-1490nm(Tx)/1570nm(Rx)-80km-commercial
specications
Item
Value
Basic Information
Module name 1.25Gbps-eSFP-SMF-1490nm(Tx)/
1570nm(Rx)-80km-commercial
Part Number 34060596
Model OGEBIDI81
Form factor eSFP
Application standard IEEE 802.3ah, 1000Base-BX80-U
