4. Cut the strap with the diagonal plier and then split the adhesive tape properly
along the seam between the cover and the body of the box with the paper
knife. Do not scratch the articles inside the box.
Figure 4-258 Unpacking the carton of the NetEngine_8000_F2A-8K36H
1. Pressure-sensitive
adhesive tape
2. Carton label 3. Packing box
4. Foam protector 5. Chassis -
5. Open the carton and take out the chassis box from the carton.
6. Open the chassis box and take out the chassis. Then, check whether the
chassis is damaged.
4.2.5 Installing a chassis in a Cabinet
Precautions
Ensure that the cabinet has been properly installed before installing devices in the
cabinet. The cabinet can be installed on an ESD
oor or concrete oor.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 607
