Huawei NetEngine 8000 F User Manual

3.4.19.6 100Gbps(4*25.7)-QSFP28-SMF-1295.56~1309.14nm-40km-
commercial
Table 3-214 100Gbps(4*25.7)-QSFP28-SMF-1295.56~1309.14nm-40km-
commercial specications
Item Value
Basic Information
Module name 100Gbps(4*25.7)-QSFP28-
SMF-1295.56~1309.14nm-40km-
commercial
Part Number 02312NVQ
Model QSFP28-100G-1310-40km-SM
Form factor QSFP28
Application standard IEEE 802.3 100GBASE-ER4
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 103.125 Gbit/s
Target transmission distance [km] 40 km
Transmitter Optical Characteristics
Center wavelength [nm] 1295.56 nm
1300.05 nm
1304.58 nm
1309.14 nm
Tx operating wavelength range [nm] 1294.53 nm - 1296.59 nm
1299.02 nm - 1301.09 nm
1303.54 nm - 1305.63 nm
1308.09 nm - 1310.19 nm
Maximum Tx optical power (AVG)
[dBm]
per lane: 2.9 dBm
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 281
