Item Value

Center wavelength [nm] 1295.56 nm

1300.05 nm

1304.58 nm

1309.14 nm

Tx operating wavelength range [nm] 1294.53 nm - 1296.59 nm

1299.02 nm - 1301.09 nm

1303.54 nm - 1305.63 nm

1308.09 nm - 1310.19 nm

Maximum Tx optical power (AVG)

[dBm]

per lane: 6.5 dBm

Maximum Tx optical power (OMA)

[dBm]

Minimum Tx optical power (AVG)

[dBm]

per lane: 2 dBm

Minimum Tx optical power (OMA)

[dBm]

Minimum extinction ratio [dB] 6 dB

Receiver Optical Characteristics

Rx operating wavelength range [nm] 1294.53 nm - 1296.59 nm

1299.02 nm - 1301.09 nm

1303.54 nm - 1305.63 nm

1308.09 nm - 1310.19 nm

Rx sensitivity (AVG) [dBm] per lane: -28 dBm

Rx sensitivity (OMA) [dBm] -

Overload power (AVG) [dBm] per lane: -3.5 dBm

Overload power (OMA) [dBm] -

NOTE

1. If the module needs to reach the nominal data, the board FEC function must be enabled.

2. The BER 5x10E - 5 is the data that is not enabled by FEC, so that 1x10E - 12 can be

reached after FEC .

3. When the board is used for 80 km transmission, it must be interconnected with a Huawei

optical module of the same model.

HUAWEI NetEngine 8000 F

Hardware Guide 3 Hardware Description
