3.4.18.4 50Gbps-QSFP28-SMF-1309nm(Tx)/1295nm(Rx)-40km-commercial
Table 3-208 50Gbps-QSFP28-SMF-1309nm(Tx)/1295nm(Rx)-40km-commercial
specications
Item Value
Basic Information
Module name 50Gbps-QSFP28-SMF-1309nm(Tx)/
1295nm(Rx)-40km-commercial
Part Number 02312EVY
Model QSFP28-50G-BIDI-40km-SM-1
Form factor QSFP28
Application standard IEEE 802.3bm-2015, 50GBASE-BR40
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12(after FEC)
<2x10E-4(before FEC)
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 53.125 Gbit/s
Target transmission distance [km] 40 km
Transmitter Optical Characteristics
Center wavelength [nm] 1309 nm
Tx operating wavelength range [nm] 1308.09 nm - 1310.19 nm
Maximum Tx optical power (AVG)
[dBm]
8 dBm
Maximum Tx optical power (OMA)
[dBm]
9 dBm
Minimum Tx optical power (AVG)
[dBm]
1.5 dBm
Minimum Tx optical power (OMA)
[dBm]
4.5 dBm
